Metal Extruder Bursting Disks
S-EB / S-EB-SVT
The S-EB series provides the overpressure protection of extruders as a purely passive safety element in addition to pressure and temperature sensors. The bursting disk body is screwed into the extruder housing in a manner that the bursting disc is positioned as close as possible to the product. Thus the bursting disc is not blocked by product deposits and can be opened unimpaired, in order to relieve unwanted overpressures – this is the only way the sensitive machine components can be protected reliably.
Models
- S-EB
- STRIKO – Extruder Bursting disk
- S-EB-SVT
- STRIKO – Extruder Bursting disk (SVT = integrated burst indicator)
Advantages in the application
- can be delivered in different sizes and lengths
- good working ratio: up to 80%
- can be used as a purely passive safety element in addition to pressure and temperature sensors
- S-EB-SVT with integrated burst indicator
- ideal for use in case of high pressures and temperatures
Specifications
- Materials
- Stainless steels, Inconel, nickel, special materials such as hastelloy
- Nominal width / length
- 3/16“ / 46mm up to 460mm (more upon request)
- Burst pressures
- from 70 bar (g) to 1200 bar (g)
- Work relationship
- 80 %
- Burst tolerance
- min +/- 5 %
- Utilisation temperature range
- depending on the application up to +500 ℃
- Burst indicator
- see SEB-SVT
Select your metal extruder bursting disks
Select a model and add your application details. This is an enquiry selection; Sightflow will confirm the final specification. Fields marked * are required.
